| Pressure angle |
20° |
| Material |
C45 |
| Heat treatment |
Induction hardened |
| Tooth surface treatment |
- |
| Rack surface treatment |
- |
| Tooth surface finish |
Milled |
| Precision grade |
DIN 9 |
| Racks for continuous mounting |
|
| THC Rack # |
Pitch |
L |
B |
H |
h |
f |
No. of
teeth |
Type |
Weight
(kg) |
| SRCP10-800HE |
10 |
800 |
29 |
29 |
25.82 |
2 |
80 |
R1 |
4.80 |
| SRCP12.5-800HE |
12.5 |
800 |
39 |
39 |
35.02 |
2 |
64 |
R1 |
9.80 |
| SRCP16-800HE |
16 |
800 |
49 |
49 |
43.91 |
2 |
50 |
R1 |
14.20 |
| SRCP20-800HE |
20 |
800 |
59 |
59 |
52.63 |
2 |
40 |
R1 |
20.20 |
| SRCP25-800HE |
25 |
800 |
79 |
79 |
71.04 |
2 |
32 |
R1 |
35.70 |
| |
| SRCP10-1200HE |
10 |
1200 |
29 |
29 |
25.82 |
2 |
120 |
R1 |
7.20 |
| SRCP12.5-1200HE |
12.5 |
1200 |
39 |
39 |
35.02 |
2 |
96 |
R1 |
13.50 |
| SRCP16-1200HE |
16 |
1200 |
49 |
49 |
43.91 |
2 |
75 |
R1 |
21.20 |
| SRCP20-1200HE |
20 |
1200 |
59 |
59 |
52.63 |
2 |
60 |
R1 |
30.30 |
| SRCP25-1200HE |
25 |
1200 |
79 |
79 |
71.04 |
2 |
48 |
R1 |
53.60 |
| |
| SRCP10-2000HE |
10 |
2000 |
29 |
29 |
25.82 |
2 |
200 |
R1 |
12.00 |
| SRCP12.5-2000HE |
12.5 |
2000 |
39 |
39 |
35.02 |
2 |
160 |
R1 |
22.50 |
| SRCP16-2000HE |
16 |
2000 |
49 |
49 |
43.91 |
2 |
125 |
R1 |
35.30 |
| SRCP20-2000HE |
20 |
2000 |
59 |
59 |
52.63 |
2 |
100 |
R1 |
50.50 |
| SRCP25-2000HE |
25 |
2000 |
79 |
79 |
71.04 |
2 |
80 |
R1 |
89.30 |
Note:
1.All dimensions are in mm.
